    High Pressure Paper Testing Equipments FOR Fabric Bursting Strength

    Ask Lasest Price
    Brand Name : HAIDA
    Certification : ISO 9001:2000; ISO 9001:2008; QS-9000; ISO 14001:2004; CE, , SMC, CMC, CPA, CE,CMA,IMC
    Model Number : HD-A504-A
    Price : Negotiable
    Delivery Time : 20 days after order confirmed
    Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow
    Supply Ability : 300 Sets per Month Haida
    • Product Details
    • Company Profile

    High Pressure Paper Testing Equipments FOR Fabric Bursting Strength

    High Pressure Paper Testing Equipments FOR Fabric Bursting Strength


    Specifications


    Fabric Bursting Strength Testing Machine
    1.High quality with reasonable price
    2.One year free after-sale service
    3.Up to TAPPI-T804,AS


    The product Description:


    Fabric Bursting Strength Testing Machine is fit for products which are packaged by corrugated paper such as electronic instruments, electric ware, hardwares, bike, valise, food, shoe, furniture etc, to test the bursting-resistance strength of paper box; it can also test cloth and synthetic leather. The GT-7013-ADP type of bursting strength tester is adapted with signal output of pressure. While specimen is breaking, the max. breaking value will be kept with the alarm buzzer & alert light automatically. Its Accuracy has promoted 20 times more than the traditional gauge.

    The parameters:

    Model

    HD-A504

    Capacity (Optional)

    High Pressure 0~100 Kg/ cm^2 (0.1kg/cm^2)

    Unit (sitchable)

    Kpa, psi, kg/cm^2

    Accuracy

    ± 0.5%

    Pressure Range

    250~5600kpa

    Speed of Compression

    High Pressure 170± 10ml/min

    Specimen Clamping Force

    >690kpa

    Oil

    85% Glycerin; 15% Distilled Water

    Sensing method

    Pressure Transmitter

    Indicating Method

    Digital

    Display

    LCD

    Material of the Ring

    Stainless Steel SUS304

    Opening in Upper Clamp

    31.5 ± 0.05 mm Diameter

    Opening in Lower Clamp

    31.5 ± 0.05 mm Diameter

    Motor

    Anti-vibration Motor 1/4 HP

    Operation Method

    Semi-automatic

    Dimension (L×W×H)

    430×530×520 mm

    Weight

    Approx. 64 kg

    Power

    1 , AC220± 10%, 50 Hz

    Power Capacity

    120W

    Standard Configuration

    Rubber Membrane 1 piece, Spanner 1 set, Correction Shim 10 sheets, Glycerin 1 bottle

    Optional Configuration

    Printer

    Standard

    JIS-L1004, L1018, L1031, K6328, P8131, P8112
    ASTM-D2210; TAPPIT403TS-63
    ISO2759-2001; GB/T1539
